Specifications

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	2-Stroke
Engine - Cooling	Liquid
Engine - Valves	0
Engine - Valves Per Cylinder	0
Engine - Valve Configuration	Reed Valve
Engine - Bore (mm)	58
Engine - Bore (in)	2.28
Engine - Stroke (mm)	54.5
Engine - Stroke (in)	2.15
Engine - Displacement (cc)	143.6
Engine - Displacement (ci)	8.8
Engine - Starter	Kick
Engine - Fuel Requirements	Premium
Engine - Fuel Type	Gas / Oil Premix
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Mikuni
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	38
Carburetion - Carburetion Type	Carburetor

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Gear Ratio (1)	2.46
Transmission - Gear Ratio (2)	2
Transmission - Gear Ratio (3)	1.65
Transmission - Gear Ratio (4)	1.4
Transmission - Gear Ratio (5)	1.21
Transmission - Gear Ratio (6)	1.09
Transmission - Reverse	No
Transmission - Final Drive Ratio	3.69

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Wheelbase (in)	58.5
Dimensions - Wheelbase (mm)	1485
Dimensions - Ground Clearance (in)	14.8
Dimensions - Ground Clearance (mm)	375
Weight	Standard
Capacities	Standard
Capacities - Fuel Capacity (gal)	1.9
Capacities - Fuel Capacity (l)	7.2
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Chromium Molybdenum
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Exterior Guards	Standard
Exterior Guards - Chassis Protectors	No
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Exterior Covers - Side Cover	No
Exterior Covers - Fuel Tank Cover	No
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard
Handlebar Pads	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Inverted Fork
Front Suspension - Front Suspension Size (in)	1.9
Front Suspension - Front Suspension Size (mm)	48
Front Suspension - Front Travel (in)	12.2
Front Suspension - Front Travel (mm)	310
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Front Suspension Brand Name	WP AER
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	11.8
Rear Suspension - Rear Travel (mm)	300
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	WP
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubed
Wheels - Front Wheel Width (in)	1.6
Wheels - Rear Wheel Width (in)	2.15
Tires	Standard
Tires - Tire Brand	Dunlop®
Tires - Front Tire Width	80
Tires - Front Tire Aspect Ratio	100
Tires - Front Tire Speed Rating	M
Tires - Front Wheel Diameter	21
Tires - Rear Tire Width	100
Tires - Rear Tire Aspect Ratio	90
Tires - Rear Tire Speed Rating	M
Tires - Rear Wheel Diameter	19
Tires - Front Tire (Full Spec)	Dunlop® GEOMAX MX3S 80/100 R21 51M
Tires - Rear Tire (Full Spec)	Dunlop® GEOMAX MX3S 100/90 R19 57M

BRAKES

Brakes	Standard
Brakes - Brake Brand Name	Brembo®
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Front Brake Diameter (in)	10.2
Brakes - Front Brake Diameter (mm)	260
Brakes - Rear Brake Type	Hydraulic Disc
Brakes - Rear Brake Diameter (in)	8.7
Brakes - Rear Brake Diameter (mm)	220

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	37.8
Seat Specifications - Seat Height (mm)	960
Seat Specifications - Number Of Seats	1

CONVENIENCE

Adjustable Handlebars

Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No
Decal Kit	Standard

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
